6GK5108-2QS00-3AR3 Switch công nghiệp 8 cổng PoE RJ45 1GE + 2 cổng SFP 10GE SCALANCE XR108-2PoE WG Unmanaged & Layer 2
Liên hệ
SCALANCE XR108-2PoE WG; unmanaged IE Switch; 19″ rack; 8 x 1GE electrical PoE ports; 2 x SFP 10GE port; LED diagnostics power supply 240 V AC (85 – 264 V).
Tải về datasheet (pdf): Tại đây!
6GK5108-2QS00-3AR3 là switch công nghiệp “industrial ethernet switch” (bộ/thiết bị chuyển mạch công nghiệp) được hãng SIEMENS sản xuất & phát triển dưới tên thương hiệu sản phẩm SCALANCE. 6GK5108-2QS00-3AR3 được MESIDAS GROUP phát triển và phân phối rộng rãi trên thị trường Việt Nam. Nếu quý khách hàng đang có nhu cầu cần tư vấn, báo giá hay mua 6GK5108-2QS00-3AR3 thì hãy liên hệ MESIDAS.COM để được hỗ trợ một cách tận tâm, nhanh chóng và hiệu quả nhé.
Mục lục
Bảng tóm tắt thông số kỹ thuật 6GK5108-2QS00-3AR3
SCALANCE XR108-2PoE WG; unmanaged IE Switch; 19″ rack; 8 x 1GE electrical PoE ports; 2 x SFP 10GE port; LED diagnostics power supply 240 V AC (85 – 264 V)
| Mã sản phẩm | 6GK5108-2QS00-3AR3 |
| Dòng sản phẩm | SCALANCE XR108-2PoE WG |
| Hãng sản xuất | SIEMENS |
| Số lượng cổng | 8 x 1GE electrical PoE ports;
2 x SFP 10GE port |
| Nguồn cung cấp | 240 V AC (85 … 264 V AC) |
| Kích thước (RxCxS) | 482.6 x 43.6 x 133 mm |
| Trọng lượng | 2 900 g |
Bảng chi tiết thông số kỹ thuật 6GK5108-2QS00-3AR3
| Article number | 6GK5108-2QS00-3AR3 |
| product type designation | SCALANCE XR108-2PoE WG |
| transfer rate | |
| transfer rate | 10 Mbit/s, 100 Mbit/s, 1 000 Mbit/s, 10 Gbit/s |
| interfaces for communication integrated | |
| number of electrical connections | |
| ● for network components or terminal equipment | 8; RJ45 |
| ● for Power-over-Ethernet for network components or terminal equipment | 8 |
| number of optical interfaces for network components or terminal equipment | 2 |
| number of 10/100 Mbit/s RJ45 ports integrated | |
| number of 10/100/1000 Mbit/s RJ45 ports integrated | |
| ● with PoE | 8 |
| number of electrical connections | |
| ● for SFP+ | 2 |
| interfaces other | |
| number of electrical connections | |
| ● for power supply | 1 |
| type of electrical connection | |
| ● for power supply | IEC plug C14 |
| supply voltage, current consumption, power loss | |
| product component connection for redundant voltage supply | Yes |
| type of voltage supply redundant power supply unit | No |
| supplied active power of PSE with PoE | |
| ● per port maximum | 60 W |
| ● total maximum | 200 W |
| type of voltage 1 of the supply voltage | |
| ● supply voltage 1 rated value | 240 V |
| ● power loss [W] 1 rated value | |
| ● supply voltage 1 rated value | 85 … 264 V |
| ● consumed current 1 maximum | 4 A |
| ● type of electrical connection 1 for power supply | |
| ● product component 1 fusing at power supply input | Yes |
| ambient conditions | |
| ambient temperature | |
| ● during operation | 0 … 60 °C |
| ● during storage | -40 … +85 °C |
| ● during transport | -40 … +85 °C |
| relative humidity | |
| ● at 25 °C without condensation during operation maximum | 95 % |
| protection class IP | IP30 |
| design, dimensions and weights | |
| design | 19″ rack |
| number of modular height units relating to 19-inch cabinet | 1 |
| width | 482.6 mm |
| height | 43.6 mm |
| depth | 133 mm |
| net weight | 2.9 kg |
| material of the enclosure | metal |
| fastening method | |
| ● 19-inch installation | Yes |
| ● 35 mm top hat DIN rail mounting | No |
| ● wall mounting | No |
| ● S7-300 rail mounting | No |
| ● S7-1500 rail mounting | No |
| product features, product functions, product components general | |
| cascading in cases of star topology | any (depending only on signal propagation time) |
| product functions management, configuration, engineering | |
| product function | |
| ● multiport mirroring | No |
| ● CoS | Yes |
| product function switch-managed | No |
| product functions redundancy | |
| product function | |
| ● Parallel Redundancy Protocol (PRP)/operation in the PRP-network | Yes |
| ● Parallel Redundancy Protocol (PRP)/Redundant Network Access (RNA) | No |
| standards, specifications, approvals | |
| standard | |
| ● for FM | |
| ● for safety from CSA and UL | UL 62368-1, CSA C22.2 No. 62368-1 |
| ● for emitted interference | EN 61000-6-4 |
| ● for interference immunity | EN 61000-6-2 |
| MTBF | 47 y |
| standards, specifications, approvals CE | |
| certificate of suitability CE marking | Yes |
| standards, specifications, approvals hazardous environments | |
| standard for hazardous zone | |
| ● from CSA and UL | |
| certificate of suitability | |
| ● ATEX | |
| ● IECEx | |
| ● CCC for hazardous zone according to GB standard | |
| standards, specifications, approvals other | |
| certificate of suitability | |
| ● C-Tick | Yes |
| ● KC approval | Yes |
| ● railway application in accordance with EN 50155 | No |
| ● related to FCC | |
| ● FCC, Part 15, Section B, Class b | |
| ● EC Declaration of Conformity EN 61010, IEC 61010-1, UL 61010A-1 | |
| ● EAC approval | Yes |
Phân phối & báo giá 6GK5108-2QS00-3AR3
Nếu quý khách hàng đang có nhu cầu cần tư vấn, báo giá hay mua 6GK5108-2QS00-3AR3 thì hãy liên hệ MESIDAS.COM để được hỗ trợ một cách tận tâm, nhanh chóng và hiệu quả nhé.
